ABOUT LED BACKLIT LOGO
Plan your project around LED backlit logo signs.
As a professional sign factory, we build custom LED backlit logo signs from your brand artwork: each piece with its own light source and circuit, fabricated to shape with LEDs inside and an opal acrylic back-panel toward the wall, for a soft halo, UL Listed and backed by a 3-year limited warranty.
Once you approve the shop drawings, we start production. Production usually runs about 15 business days, and DHL door-to-door shipping then takes about a week, for a total of about 4 weeks from drawing approval to delivery.
What are LED backlit logo signs?
LED backlit logo signs take your whole brand logo, the icon or symbol and the wordmark together, and rebuild it as one dimensional, lit piece. Each piece has its own light source and its own circuit, made as a hollow metal logo shell (called a channel in the U.S.), rather than cut from solid metal. The face is laser cut, and the returns (the side walls) are fabricated to the outline of your logo and laser welded to the face into one hollow piece. The metal logo shell is open toward the wall, and that opening is closed with an opal acrylic back-panel that lets the light through. The Luxury model mounts flush against the wall by default and can also mount off the wall, while the Common model always mounts off the wall. Whenever a sign mounts off the wall, we supply stainless steel tube spacers. In both models, the low-voltage LEDs inside shine through the back-panel onto the wall, where the light forms a soft halo in the shape of your logo. Unlit, it reads as a crisp dimensional metal logo. Lit, the whole logo glows on the wall. What matters most is faithful reproduction: the icon, the curves, the proportions, and the colors all follow your artwork. It comes down to what can be fabricated as a lit piece that houses its own LEDs, so where your logo can be built we follow it closely, and where a line is too thin or a detail too small to hold the LEDs and keep its shape, we make the smallest change that keeps your design intent. A multi-color logo is color-matched in the face finish, while the LED glow color is chosen separately. The metal logo shells are 304 stainless steel by default, marine-grade 316 for coastal sites, and aluminum on large logos (on the Common model) to cut weight. The same build makes LED backlit letters and, with deeper returns, 3D LED backlit signs.
Common applications and related pages
Your logo is the face of your brand, so putting it on the wall as a lit, dimensional piece works hard for you: unlit it reads as a metal brand mark, and lit the whole logo glows. This kind of signage suits businesses that want their identity to stand out, indoors or out, and the signage carries from a reception desk to a rooftop. Here are a few typical industries, and you can see all the industries we serve.
A clean, well-made logo sign puts your company image on the wall and helps draw in customers, making your brand mark the thing people remember. Signs do bring customers: in a national survey, 76% of consumers had walked into a store they had never visited before because of its signage (per FedEx Office)1.
What we need for your custom project
- Design file
- A vector file works best for a logo, so the curves and corners stay true. A high-resolution raster or an AI-generated flat image is enough for a quote. Skip software auto-tracing: it distorts the logo, so send the high-resolution artwork as it is.
- Property sign rules
- Before any design work starts, check the sign rules with your landlord or property manager: the allowed size range, any finish or color requirements, light color temperature limits, and the required mounting method. If the property has written sign criteria, send them to us directly, and both the quote and the shop drawings will follow them.
- Sizes
- Set the logo overall size and proportions within the range your property allows, then size it to the viewing distance: as a rule of thumb, a sign reads clearly up to about 120 times the height of its smallest key element. A logo has to size up for the road, too: in a national shopper study, 90.9% agreed that sign letters need to be big enough to read from a passing car (per BrandSpark)3.
- Wall
- Send a photo of the wall where the sign will hang. Wall color and texture affect how bright the reflected halo reads (especially on the Common model), so the photo helps us plan the mounting method and advise on the light color temperature.
- Power
- By default, we use Mean Well power supplies. They accept 90 V to 264 V AC input. If the power available at your site is different or unusual, tell us before production, so we can match the right power supply for you.
- Indoor or outdoor
- Describe exactly where the sign will be installed: indoors, outdoors, or on a coastal site. For an outdoor sign in an extreme climate (high heat, heavy rain, cold, or dust), tell us before we lock the production details.
- Finish
- Choose from a full range:
- Mirror polished
- Brushed
- Vibration finish
- Painted or powder-coated color, in gloss, semi-gloss, or matte (tell us the exact color and we color-match to Pantone, RAL, Sherwin-Williams (SW), or Matthews Paint (MP) swatches)
- Plated metal colors (gold, black titanium, copper, and more)
- Special effects such as wood grain, antique, and marble look
- Light color
- White: 3000K warm white, 4000K natural white, or 6000K white
- Red, yellow, blue, or green
- Color-changing: RGB, or RGBW (RGB plus a dedicated white channel)
- Another single color or a specific color temperature: tell us, and we set it up for you.
Light colors are approximate and are not matched to color swatches.
Choosing your model: Luxury or Common
LED backlit logo signs come in two models, the Luxury model and the Common model, and they differ in how the halo forms. On the Luxury model the acrylic back-panel is partly exposed outside the metal sign shell, and the light leaves from that exposed edge straight onto the wall, which is why it mounts flush against the wall by default and gives a brighter, wider halo. On the Common model the back-panel sits fully inside the metal sign shell, the halo forms by reflection off the wall, and the sign has to stand off the wall for that to happen. See the point-by-point comparison in Compare below.
Luxury model
- Opal acrylic back-panel partly exposed, with a stronger halo
- Mounts flush against the wall by default, or off the wall on stainless steel tube spacers
- Suits premium storefronts and brand walls
View Luxury Model Common model- Opal acrylic back-panel hidden inside the metal logo shell
- Must mount off the wall, on 13/16 in (20 mm) stainless steel tube spacers by default
- Suits storefronts, large logos, curved walls, and outdoor sites
View Common Model Installation and electrical
Installation
- Installation is arranged on your side: we recommend a professional sign installer, with an electrician making the final electrical connection (you can find both on Yelp or Google Maps). Professional installation gives the sign a longer life, a better look on the wall, and safer, more reliable wiring. The job covers drilling the wall, setting stud bolts, routing wires, placing the power supply, and low-voltage wiring.
- We supply a 1:1 mounting template, the wiring diagram, the installation instructions, and the mounting hardware, such as stud bolts and a Mean Well power supply. Because a logo often pairs an icon with a wordmark, the template keeps the finished sign aligned and correctly spaced.
- If the wall can’t take many holes, we can mount all the pieces on a metal backer box at the factory, so the sign goes up as one piece.
- The Common model must mount off the wall for the reflected halo to form, so we include stainless steel tube spacers, 13/16 in (20 mm) long by default, which also hide the studs and wiring. If you want a different off-wall distance, tell us in advance. The Luxury model mounts flush against the wall by default, and when it mounts off the wall, it uses the same stainless steel tube spacers.
Power supply
- The power supply usually sits behind the wall or above the ceiling, in a spot that sheds heat and stays accessible for service.
- For U.S. projects, we plan a 12V DC low-voltage system with a UL Listed Mean Well power supply before production. The wiring must follow our wiring diagram exactly, so each letter’s load matches its power supply, and the sign must never be connected to a supply that does not match the power supply’s input.
Outdoor planning
- 304 stainless steel by default. For a coastal or near-coast site, tell us: the metal logo shells and all the mounting hardware are then made in marine-grade 316 stainless steel.
- Outdoor signs use waterproof LEDs by default. For rainy regions we upgrade them to IP67 and plan drainage holes at the bottom of the metal logo shells, plus edge detailing that keeps the halo outline clean.
LED backlit logo signs FAQ notes
- Can you reproduce our exact logo, symbol and all, not just the text?
- Yes. We rebuild the icon, the shapes, and the wordmark as dimensional lit pieces. The limit is what can be fabricated as a lit piece that houses its own LEDs, so where the artwork can be built we follow it closely, and where a line is too thin or a detail too small to hold the LEDs we make the smallest change that keeps your design intent. We confirm all of it in the shop drawings before production.
- Our logo has several brand colors. How does that work on a backlit logo sign?
- The face is painted or finished and color-matched to Pantone, RAL, Sherwin-Williams (SW), or Matthews Paint (MP) swatches, so your brand colors are exact. The LED glow color is a separate choice (3000K warm white, 4000K natural white, 6000K white, a single color, or RGB or RGBW color-changing): the face color and the light color are two different things, and we set both in the shop drawings.
- Can the icon and the wordmark be separate pieces, or combined into one?
- Either way. They can be mounted as separate pieces for an airy look, or fixed to one metal backer box for a single unit. We plan the layout and mounting in the shop drawings.
- How does backlighting look on a solid logo shape versus open letters?
- A solid metal logo shell throws a halo of its whole silhouette onto the wall, which reads bold and clean. For an intricate or open shape, we plan the LED layout inside so the halo glows evenly across the mark.
- Indoors or outdoors, and which model suits a logo?
- Both work. For an indoor brand wall we usually suggest the Luxury model: it mounts flush against the wall by default, and its partly exposed acrylic back-panel sends the light straight onto the wall for a brighter halo. For outdoor or oversized logos the Common model mounts off the wall and has better weather resistance. Send us your site and we will recommend the fit.
